Synaptics Video Interface
| 产品型号 Part No. |
|---|
| VMM3332 |
| VMM52xx |
| VMM53xx |
| VMM6100 |
| VMM62xx |
| VMR7100 |
| VMM7100 |
| VMM94xx |
| VMM84xx |
| DL-3900 |
| DL-41xx |
| DL-6xxx |
| DL-74xx |
|
产品系列 Product Series |
输入 Input |
输出 Outputs |
最高可支持 Max Resolutions |
封装类型 Package |
最小卷装 MOQ |
|---|---|---|---|---|---|
| DispalyPort | DP1.2 | DP1.2/HDMI1.4/VGA | 1*4K30Hz/3*1080P | BGA | 2Ku |
| DispalyPort | DP1.4 | DP1.4/HDMI2.0 | 1*4K60Hz/2*4K60Hz | BGA | 2Ku |
| DispalyPort | DP1.4 | DP1.4/HDMI2.0 | 1*4K60Hz/3*4K60Hz | BGA | 2Ku |
| DispalyPort | DP1.4 | HDMI2.1 | 1*8K30Hz | BGA | 4.5Ku |
| DispalyPort | DP1.4 | DP1.4/HDMI2.1/HDMI2.0 | 1*8K30Hz/2*4K60Hz | BGA | 4Ku |
| DispalyPort | DP1.4 | HDMI2.0 | 1*4K60Hz | BGA | 4.5Ku |
| DispalyPort | DP1.4 | HDMI2.1 | 1*8K60Hz | BGA | 4.5Ku |
| DispalyPort | DP2.1 | DP2.1/HDMI2.1 | 1*8K60Hz/2*8K60Hz/4*4K120Hz | BGA | 2Ku |
| DispalyPort | DP1.4 | DP1.4/HDMI2.1 | 1*8K60Hz/4*4K60Hz | BGA | 2Ku |
| DisplayLink | USB3.1 G1 | HDMI1.4/VGA | 2*FHD60Hz | BGA | 900pcs |
| DisplayLink | USB3.1 G1 | LVDS | 1*FHD60Hz | BGA | 600pcs |
| DisplayLink | USB3.1 G1 | DP1.2/HDMI2.0 | 4*4K60Hz | BAG | 840pcs |
| DisplayLink | USB3.1 G2/PCIE | DP1.4/HDMI2.0 | 2*8K60Hz/4*4K120Hz | BAG | 900pcs |
Synaptics Touch（PC)
| 产品型号 Part No. |
|---|
| S7813 |
| S7817 |
|
通道数 （Channel) |
Interface |
Support Panel Size |
Feature | Power Consumption |
封装类型 Package |
封装尺寸 |
|---|---|---|---|---|---|---|
| 60*36 | I2C/SPI | 14' | Touch + 1mm passive Pen + Glove + LPWG | Active: 181 mW Idle: 4 mW Sleep: 0 mW | BAG | 5*10.5*0.6 |
| 72*46 | I2C/SPI | 17.3' | Touch + 1mm passive Pen + active pen + Glove + LPWG | Active:124.955 mW Idle: 8.308 mW Sleep: 0 mW | BAG | 5*10.5*0.6 |
Synaptics Touch (Auto)
| 产品型号 Part No. |
|---|
| S7880 |
| S7881 |
| S7882 |
| S7883 |
| S7885 |
|
通道数 （Channel) |
Interface |
Support Panel Size |
Feature | Temp. Range |
封装类型 Package |
封装尺寸 |
|---|---|---|---|---|---|---|
| 43(17*26) | I2C/SPI | 7.5 | glove+Moisture | -40°C~+105°C | 64TQFP | 10*10*1 |
| 60(16*44) | I2C/SPI | 11" | glove+gesture+Moisture | -40°C~+105°C | 128LQFP | 20*14*1.6 |
| 76(28*48) | I2C/SPI | 14" | glove+gesture+Moisture | 40°C~+105°C | 128LQFP | 20*14*1.6 |
| 80(29*51) | I2C/SPI | 15" | glove+gesture+Moisture+proximity | -40°C~+105°C | 176LQFP | 20*20*0.6 |
| 102(65*37) | I2C/SPI | 18" | glove+gesture+Moisture+proximity | -40°C~+85°C | 176LQFP | 20*20*0.6 |
